MT-712 Computer-Controlled Bottom Floating Presser Sole Attaching Machine Shoe Sole Pressing Machine

Heavy Duty Walled Hydraulic Sole Attaching Pressing Machine For Shoes Making

1.This machine is automatically controlled by a mixture of hydraulic and pneumatic system.It is suitable for attaching the out sole of logging shoes and walled sports shoes.The pressing of bottom,sides and front-rear can be finished at one time,which saves labor and produces a good effect in every step of pressing.It is an automatic sole attaching machine for upgrading shoe manufacturing.The hydraulic system has high pressure,good attaching effect and no slackness.

2.The front-tear pressing rods adopt hydraulic automatic balancing device,which needs no adjustment.The design of automatic bias angles.Setting for mechanism of pressing rods makes.Shoes locating easy.Even for boots.The pneumatic loop goes through automatic water filter,which keeps the air in the compressor dry to ensure low failure or air cylider and life.

3.The pressing pads for front-rear pressing are made of foaming PU material,and there are several different specifications for choosing,which can be applied to press different shapes of shoes.The leather forming bag for side pressing can automatically form as the shapes of lasts and produce an even attaching effect on both sides of shoes.This machine can be adjusted into different pressing methods for attaching differfent out soles of jogging and walled sports shoes.

Inquiry

Write a Review

Hydraulic Shoe Sole Pressing Machine

1. Hydraulic system design suitable for outsole attaching of shoes, boots, casual shoes, and kinds of walled shoes, the perfect pressing of outsole, side, toe and hell forming can be accomplished simultaneously or separately

2.There is a prepared oil-tank to supplement oil when cylinder rising which makes the rising faster and saves the operation time to increase benefit

3.When the mechanism of front-rear pressing recedes, a special circuit device is adopted to control the receding stroke, and the proper receding distance is accordingly for locating different sizes of shoes

4.Independent pressure adjustment, adjustment handle in the front of machine. This machine is available to press shoes with lasts between130mm and 400mm in length, 140mm in width, below 190mm in height, below 80mm in height of walled outsoles, such as jogging, walled sports and casual shoes.

Key attributes

Model	Power	Oil Pressure	Production Capacity	Voltage	Weight (KG)
MT-712	2.2KW	50Kg/Cm²	250Pairs/Hour	380V/50HZ	1140

Applicable Industries	Manufacturing Plant,Other	Weight (KG）	1140
Showroom Location	None	Video outgoing-inspection	Provided
Machinery Test Report	Provided	Marketing Type	Ordinary Product
Warranty of core components	1 Year	Core Components	Engine,Bearing,Motor,Pressure vessel
Place of Origin	Fujian,China	Warranty	1 Year
Condition	New	Brand Name	MingTeng
Brand	MT	Useful	Shoes Making
Color	Customers'Demand	Key words	Shoe Machine Industry
Shipping	15days	After Warranty Service	Technical Video Support
Machine	Shoe Machine Line	DIMENSION	109x100x196CM
