MT-804 Low Temperature Flexing ,Cold Resistance Tester for Rubber, Footwear, Leather and Apparel Accessories Durability Testing
Product Overview
This machine is used to test the bending/flexing durability of rubber, plastic, shoe soles, synthetic leather and other materials under specified cold conditions. Samples are fixed in appropriate clamping fixtures and continuously flexed in a controlled low-temperature environment to assess cold-weather performance. The chamber is stainless steel for durability and insulation, and the unit is equipped with a Japanese RKC PID controller for precise temperature control—suitable for R&D and QC labs.According to the standard
ASTM-D1790, D1593, 1052, JIS-K6545, HB-T2877, CNS-7705, ISO20344, GB/T20991-2007
Features
-
Stainless Steel Chamber: Corrosion-resistant, durable, and easy to maintain.
-
Precise Temperature Control: Japanese RKC PID controller ensures accuracy and stability.
-
Rapid Cooling: Reaches -30°C from room temperature within 60 minutes.
-
Multiple Clamping Fixtures: Suitable for different materials and test standards.
-
Observation Window: Double-layer vacuum glass for clear monitoring during tests.
-
Safety Protection: Over-temperature and overload protection for operator safety.
Applications
-
Rubber and plastic material low temperature performance testing
-
Shoe sole and upper flexing durability evaluation in cold conditions
-
Leather and synthetic leather flexibility inspection
-
Fabric and apparel accessory cold resistance testing
-
R&D for extreme-weather material development
| Item | Specification |
|---|---|
| Chamber material | Stainless steel |
| Controller | Japanese RKC PID controller |
| Temperature range | Room temperature to -30°C (optional -50°C upon request) |
| Cooling Down | Room temp → -30°C within ~60 minutes |
| Temperature accuracy | ±0.3°C |
| Temperature uniformity | ±1°C |
| Temperature resolution | 0.1°C |
| Thermal insulation material | Rigid polyurethane foam + glass wool |
| Refrigerant | R404A |
| Compressor starting delay | 5 minutes |
| Power consumption | 4–6 kW |
| Viewing window | 210 × 350 × 270 mm (please confirm final size) |
| Window lamp | 1 × lamp, 5 W |
| Counter | LCD counter, 0–999,999 (please confirm max count) |
| Motor | Import non belt gear wheel reduction motor |
| Interior dimensions (W×D×H) | 600 × 600 × 550 mm |
| Overall dimensions (W×D×H) | 1200 × 1200 × 1400 mm |
| Weight | 300 kg |
| Power supply | 3φ AC380V 50Hz or 1φ AC220V 50Hz |
